Product Name：Super Wide Dynamic OSD CCD camera
Moudel Number：UOC-7935SWD (520TVL)
Feature：
●Super Wide Dynamic
●OSD (On Screen Display) function
●SENS UP technology increase sensibility to 2X-128X
●Color camera PCB Module with SHARP 1/3“ CCD sensor
●Employs Digital Signal Processor (DSP) chip-set for image control
●Pixel number : NTSC=410K / PAL=470K
●High sensitivity, low smear, high anti-blooming, and high S/N ratio
●Build-in functions: 5 push SW, language (Eng, Jan, SC), mirror,
upside down, enhance, flickless, color bar, IR-Cut-Filter SW,
gamma correction, day/night SW, title, mask, digital zoom,
DNR (Digital Noise Reduction), motion det.,
●negative image, alarm out
●RS-485 I/F, high light suppress
●Built-in anti-aliasing and IR-cut optical filter
|
MODEL NO.
|
UOC-7935SWD
|
||
|
TV SYSTEM
|
NTSC
|
PAL
|
|
|
IMAGE SENSOR
|
1/3-inch SONY CCD Image Sensor
|
||
|
CCD TOTAL PIXELS
|
811(H) X 508(V)
|
795(H) X 596(V)
|
|
|
SCANNING SYSTEM
|
525 lines, 60 fields/sec
|
625 lines, 50 fields/sec
|
|
|
SYNC SYSTEM
|
Internal / Line-Lock
|
||
|
MINIMUM ILLUMINATION
|
0.001 Lux @ F1.2 AGC on B/W
|
||
|
RESOLUTION
|
520TVL / 580TVL ((Enhanced))
|
||
|
WHITE BALANCE
|
Mode
|
ATW / AWB / FIX
|
|
|
Range
|
3200 ~ 10000 ºK
|
||
|
GAIN CONTROL
|
Mode
|
AGC (ON / OFF)
|
|
|
Range
|
0 ~ 18dB
|
||
|
S / N RATIO
|
56dB (MAX) / 50dB ( MIN)
|
||
|
AUTO IRIS
|
A.E.S. / DC
|
||
|
OSD DISPLAY
|
ON SCREEN DISPLAY FOR ALL CONTROL
|
||
|
5 PUSH SW
|
FOR OSD CONTROL PANEL
|
||
|
LANGUAGE (ENG. /JAN. / SC)
|
SELECTABLE BY OSD MANUAL
|
||
|
MIRROR FUNCTION
|
SELECTABLE BY OSD MANUAL
|
||
|
UP SIDE DOWN
|
SELECTABLE BY OSD MANUAL
|
||
|
B.L.C. FUNCTION
|
SELECTABLE BY OSD MANUAL
|
||
|
DIGITAL ZOOM (X2)
|
SELECTABLE BY OSD MANUAL
|
||
|
NEGATIVE IMAGE
|
SELECTABLE BY OSD MANUAL
|
||
|
MASKING AREA
|
SELECTABLE BY OSD MANUAL
|
||
|
DNR (Digital Noise Reduction)
|
SELECTABLE BY OSD MANUAL
|
||
|
MOTION DET.
|
SELECTABLE BY OSD MANUAL
|
||
|
ALARM OUT
|
Motion Detect
|
||
|
RS-485 I/F
|
DIM connector
|
||
|
WIDE DYNAMIC
|
52dB ( MAX)
|
||
|
VIDEO OUTPUT
|
Composite & Y/C output 1.0V p-p at 75 ohm
|
||
|
GAMMA CORRECTION
|
0.45 / 1.0 (SELECTABLE BY OSD MANUAL)
|
||
|
OPERATION TEMPERATURE
|
-20℃ TO 50℃
|
||
|
OPERATIONAL HUMIDITY
|
within 85﹪RH
|
||
|
POWER SUPPLY
|
DC12V & AC24V / 6W
|
||
