Product Name：WDR 7 Series
Moudel Number：UWDR 7 Series (540TVL)
Feature：
● 14-Bit
● Dual Channel
● 1:100,000 Wide Dynamic Range without Time Lag
● 94dB Dynamic Range
● Single Exposure
● 60 FPS Progressive
● Smear Free
● Excellent S/N (Great Sensitivity)
● High Gray-scale
● 30db Gain with 3D DNR
● Color Perfirmance Under Low Illumination
● Full OSD Functions
|
Model No.
|
UWDR 7 SERIES
|
||
|
IMAGE SENSOR
|
1/3-inch SVGA format CIS-II Sensor
|
||
|
CCD TOTAL PIXELS
|
835(H) X 625(V)
|
||
|
EFFECTIVE PIXELS
|
NTSC: 771(H) X 492(V) / PAL: 753(H) X 582(V)
|
||
|
SYNC SYSTEM
|
Internal / Line lock (3.3V VD pulse input)
|
||
|
MINIMUM ILLUMINATION
|
Less 0.01 lux @F1.2 / AGC (30dB) / SENS-UP (OFF)
|
||
|
LENS & VIEW ANGLE
|
C/CS Mount
|
||
|
RESOLUTION
|
540TVL
|
||
|
WHITE BALANCE
|
Mode
|
ATW / AWC
|
|
|
Range
|
3200 ~ 10000 ºK
|
||
|
S / N RATIO TYPICAL
|
52dB (TYP) (Gamma, Aperture, AGC OFF,3D DNR ON)
|
||
|
DYNAMIC RANGE
|
94dB
|
||
|
FRAME INTEGRRATION
|
Select by OSD (Max.10X)
|
||
|
H - MIRROR FUNCTION
|
Select by OSD
|
||
|
V - MIRROR FUNCTION
|
Select by OSD
|
||
|
B.L.C. FUNCTION
|
Select by OSD
|
||
|
ZOOM FUNCTION
|
Select by OSD
|
||
|
FLICKLESS
|
Select by OSD
|
||
|
ENHANCE
|
Select by OSD
|
||
|
GAMMA CORRECTION
|
0.45
|
||
|
GAIN CONTROL
|
AGC Auto / Menu Select by OSD (Fix 6dB,Auto 24dB,Total 30dB)
|
||
|
AUTO IRIS
|
A.E.S. / DC-IRIS
|
||
|
ICR CONTRAL
|
Select by OSD or SW (delay time adj. by OSD)
|
||
|
DNR
|
Built-in 3D_DNR (Digital Noise Reduction)
|
||
|
ELECTRONIC SHUTTER
|
A.E.S.
|
1/60(50)~1/120,000 sec.
|
|
|
FIX.
|
1/60(50), 1/100 (120), 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000sec.
|
||
|
AUX CONNECTOR
|
Option RS-485 I/F
|
||
|
VIDEO OUTPUT
|
1.0V p-p composite video at 75 ohm
|
||
|
OPERATION TEMPERATURE
|
-20℃ TO +50℃
|
||
|
OPERATIONAL HUMIDITY
|
within 85﹪RH
|
||
|
POWER SUPPLY
|
DC12V / 250mA or AC24V / 120mA
|
||
